12. Body Cover
12-4
Handle Cover
Removal
Remove the handle rear cover (screw x 5).
Disconnect the wire connectors of left & right
switches.
Remove the handle rear cover.
Caution
Open the hooks on the two end-section of the
handlebar cover as removing the cover. The,
remove the handlebar cover. Do not pull it
forcedly to avoid to breaking the hooks.
Remove the handle front cover switch wire
coupler.
Remove front cover and wire coupler.
Remove speedometer cable.
Remove the speedometer cable.
This Chapter Contents
Screws x 5
Switch wire coupler
