15. ELECTRICAL EQUIPMENT
15-9
Ignition System
Black
Blue/Yellow
Black/Blue
Black/Yellow
Green
Red
Fuse 15A
Spark plug
IG. Coil
Maim Switch
CDI.
Battery
