15. ELECTRICAL EQUIPMENT
15-12
Starting System
Starter relay
Starter Motor
Start switch
Stop switch
Battery
Main switch
Fuse 15A
Red/White
Red
Red
Black
Green/
Yellow
Yellow
/Red
Green
