3. LUBRICATION SYSTEM
3-5
Oil Tank
Removal/Installation
Remove the luggage box and seat.
Remove the body cover and right side cover.
Remove the oil input tube from oil pump, and then
drain oil to a clean container.
Remove the oil switch wire of the oil indicator.
Remove the mounting bolt on the oil tank right
side, and then remove the oil tank.
Installation in the reverse order of removal.
Air bleeding the oil tubes after installation.
Blot ×2
Oil level switch coupler
Oil tube
