15. ELECTRICAL EQUIPMENT
15-1
Maintenance Information·················· 15-2
Troubleshooting································ 15-3
Battery················································ 15-4
Charging System······························· 15-5
Ignition System·································· 15-9
Starting System·································· 15-12
Oil Level Switch ································· 15-15
Fuel Unit ············································· 15-16
Switch / Horn······································ 15-18
Bulb Replacement······························ 15-20
15
Spark Plug
AC. Generator
Fuse Box
Battery
IG. Coil
Fuel Unit
Main Switch
Reg. Rec. Comp
Start Switch
Start Relay
Horn
Horn / Winker /
Dimmer Switch
Thermo switch
Meter
Resistor Comp
Winker Relay
Power filter unit
CDI Unit
Oil Level Switch
Thermo switch unit
