GPIB
370B User Manual
4-41
Table 4-11: System Commands and Queries
INSTRUMENT PARAMETER COMMAND GROUP
Command Argument Link Definition
SET? Reports front panel settings.
Response is the same as return of OPC?;RQS?;DEBUG?; LONG?;
OUTPUTS?; LRSSW?, CONFIG?, CSPOL?, ACQUIRE?, HORIZ?, VERT?,
MAG?, STPGEN?, PKPOWER?, PKVOLT?, AUX?, VCSPPLY?,
MEASURE?, DISPLAY?, TEXT? followed by cursor mode response.
INIt Resets instrument as if the power was turned off, then turned back on.
Instrument functions are reset as shown below.
Function INIT Val
DISPLAY
CURSOR
DISPLAY CAL:
DISPLAY INVERT:
MEASURE
ACQUIRE
MAG
VERT OFFSET:
HORIZ OFFSET
VERT COLLECTOR:
HORIZ COLLECTOR:
STPGEN CURRENT:
STPGEN OFFSET:
STPGEN MULTI:
STPGEN PULSE:
STPGEN INVERT:
STPGEN NUMBER:
VCSPPLY
PKVOLT
PKPOWER
CSPOL
CONFIG
AUX
LRSSW
OPC
RQS
LONG
DEBUG
STORE
OFF
OFF
OFF
REPEAT
NORMAL
OFF
0.0
0.0
2.0E+0
2.0E+0
50.0E-9
0.0
OFF
OFF
OFF
5
0.0
16
0.08
PNORMAL
BSGEN
0.00
STANDBY
OFF
ON
ON
OFF
TESt? Initiates ROM and RAM check routine.
TEST ROM: <hex>, RAM <hex>
ID? Reports the instrument ID:
ID SONY_TEKTRONIX/370B, V81.1, <fwv>
<fwv> ::= current firmware version
To Next Page
