When REF curve is displayed, the f LINE cursor appears only on the
STORE or VIEW curve. The f LINE cursor is not available in NON STORE
mode.
WINDOW. The WINDOW cursor is displayed as a rectangle and can be used
in any display mode as a reference for visual checks. It can also be used to
measure small signal b (Hfe).
The WINDOW cursor has two modes, depending on whether the base point
is at the top right or bottom left corner. Cursor movement and the cursor
readout display are referenced to this base point.
CURSOR. The CURSOR control directs the Position Control buttons to the
cursor. Even when the up or down Cursor Selection button is pressed to select a
cursor, this mode is automatically selected.
Pressing the ENTER button while holding down the FAST/SHIFT button
changes the button function to TEXT, which places the 370B in the Text Edit
Mode. The Text Edit mode provides text entry to the Text Area of the display
and revision of existing text.
To enter text, select the character position in the Text Area with the left and right
Position Control buttons (left and right) and select each character from the
pre-defined set of characters with the up and down Position Control buttons. The
Text Area will display up to 24 characters.
The available characters are listed below in the order in which they are presented
by the up and down Position Control buttons: space, A, B, ... Z, space , m , u, n,
p, ., 0, 1 ,. .. ,9, –, /, * , (, ), =, space.
. The 371B substitutes the Greek letter “” for the lower-case “u ”.
To edit text, use the left and right Position Control buttons to position the cursor
on the character to be changed. Use the up and down Position Control buttons to
overwrite the character or the PAST/SHIFT button to delete the character at
which the cursor is displayed. To delete all of the text, press the left and right
Position Control buttons simultaneously.
To exit the text edit mode, press the CURSOR/TEXT button.
DISPLAY. The DISPLAY control directs the Position Control buttons to the
display offset. When the cursor is selected, this mode is automatically exited.
POSITION CONTROL. The POSITION CONTROL buttons moves the cursor or
changes the slope of the f LINE. The CURSOR LED indicator is illuminated.
