Tektronix TDS 200-Series Service Manual

Adjustment Procedures
TDS 200 Series Digital Oscilloscope Service Manual
5–3
Four Channel
Digitizing oscilloscope
Digitizing oscilloscope
Two Channel
Digitizing oscilloscope
BNC ‘T’ connector
DC voltage setup 1
+–
DC voltage
source
Dual banana to
BNC adapter
BNC cable
DC voltage setup 2
+–
DC voltage
source
Dual banana
to BNC
adapter
BNC cable
Digitizing oscilloscope
Sinewave generator setup
Leveled
sine wave
generator
Output
50 W feedthrough
terminator
(Table 5–2 and 5–3 list
proper channel)
BNC cable
Four Channel
Digitizing oscilloscope
10 inch
BNC cables
BNC ‘T’
connector
s
BNC cable
10 inch
BNC cables
10 inch BNC cable
BNC ‘T’
connector
10 inch
BNC cable
10 inch
BNC cables
Square wave
generator
Output
50 W feedthrough
terminator
(Table 5–2 and 5–3 list
proper channel)
BNC cable
Edge setup
Figure 5–2: Adjustment setups
