Tektronix TDS 200-Series Service Manual

Maintenance
6–8
TDS 200 Series Digital Oscilloscope Service Manual
No tools are required to remove the feet.
Removal. Use this procedure to remove the rear feet.
1. Place the instrument face down on a soft surface (such as an anti-static mat).
2. Slide the feet up and out of the rear case as shown in Figure 6–1.
NOTE. You may want to use a flat blade screwdriver to pry up on the foot. Use
care not to mar the surface of the rear case.
Rear foot (2)
Figure 6–1: Removing the rear feet
Rear Feet
