Maintenance
TDS 200 Series Digital Oscilloscope Service Manual
6–5
Removal and Installation Procedures
This section describes how to remove and install the major mechanical and
electrical modules. It provides the following information:
H Tools Required on page 6–6 describes the tools needed to perform the
procedures.
H List of Modules on page 6–6 describes where to locate a list of replaceable
modules.
H Summary of Procedures on page 6–7 lists the procedures for removal and
installation of modules.
H Rear Feet, on page 6–8, begins a series of procedures that describe the
removal and installation of modules.
Please read the following warning statement. Then read the following general
instructions before removing a module.
WARNING. Only qualified personnel should perform service procedures. Before
doing this or any other procedure in this manual, read the General Safety
Summary and Service Safety Summary found at the beginning of this manual.
Always disconnect the power cord before disassembling any portion of the
instrument.
Also, to prevent damage to electrical components, read Preventing ESD on
page 6–1.
1. Use Figure 10–1 (the exploded view of the instrument) on page 10–8 to give
you an overview of how the entire instrument is assembled.
2. Read the Summary of Procedures on page 6–7 to understand which
procedure to use to access a given module. Then read Tools Required on
page 6–6 for a list of tools needed to remove and install modules in the
oscilloscope.
3. If you are disassembling the oscilloscope for cleaning, refer to the Inspection
and Cleaning procedure on page 6–3 for cleaning instructions.
Preparation
