Tenda V300 User Manual

137
 Verify that the IP address of your computer is 192.168.1.X (X is a number between 2 and 254).
 Use another computer, smartphone or iPad to login.
 Clear cache of your browser, or change another browser.
 Press the RST button for about 6 seconds to reset the modem router to factory default settings, and then try
to login again.
Q2: I cannot access to internet, what should I do?
A2: Use the following method to troubleshoot the fault.
 Verify that the INTERNET LED is green and solid on.
 Verify that the modem router is connected to the internet through phone cable, Ethernet cable or 3G/4G
dongle.
 Verify that the internet parameters you entered are correct.
 Uncheck the Auto Vlan Scan option, and configure it manually.
 Reboot the modem router.
 Reset the modem router to factory default settings and configure it again.
 Contact your internet service provider for help.
Q3: I forget my WiFi password, what should I do?
A3: Use the following method to troubleshoot the fault.
 If you do not change the WiFi password, it should be 12345678.
 If you change it, you can check it on the web UI of the modem router.
 If you forget the login password of the web UI as well, reset the wireless router to factory default settings.
By default, there is no WiFi password and login name and password are both “admin”. Restore Method:
Press the RST button for about 6 seconds and then release it.
8.4 VPI/VCI List
The following table lists common ISPs and their VPI and VCI numbers. If you cannot locate your ISP and their VPI
and VCI information here, ask your ISP to provide it.
Country
ISP
VPI
VCI
Encapsulation
Australia
Telstra
8
35
PPPoA LLC
Australia
GoldenIT
8
35
PPPOA_VCMUX
Australia
Telstra Bigpond
8
35
PPPOE_LLC
Australia
OptusNET
8
35
PPPOE_VCMUX
Australia
AAPT
8
35
PPPOE_VCMUX
Australia
ADSL Direct
8
35
PPPOE_LLC
Australia
Ausie Broadband
8
35
PPPOE_LLC
Australia
Australia On Line
8
35
PPPOA_VCMUX
Australia
Connexus
8
35
PPPOE_LLC
Australia
Dodo
8
35
PPPOE_LLC
Australia
Gotalk
8
35
PPPOE_VCMUX
Australia
Internode
8
35
PPPOE_VCMUX

Tenda V300 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	64-bit WEP, 128-bit WEP, SNMP, SSID, WDS, WPA-PSK, WPA2-PSK, WPS
Supported network protocols	G.994, ANSI T1.413 2, ITU-T G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.992.3 (G.dmt.bis) Annex A/L/M, ITU-T G.992.5 Annex A, G.993.2 (VDSL2), G.993.5, G.993.2 Amd 7 (ToD), G.998.4 (G.inp), ATM, PTM
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	20 dBmW
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	White
LED indicators	DSL, LAN, Power, USB, WAN, WLAN, WPS
Antenna gain level (max)	5 dBi

Weight and Dimensions

Depth	105.2 mm
Width	157.8 mm
Height	29.4 mm
