Tenda V300 User Manual

10
internet parameters directly on your computer for internet
access.
Step 4 Click OK on the bottom of the page to apply the settings.
--End
ADSL
If the link type your internet service provider provided to you is ADSL, follow the procedures below:
Step 1 Log in to the web UI and enter the Home page.
Step 2 Link Type: Select ADSL.
Step 3 Connection Type: Select a connection type according to the instructions in the table below, and
complete the related internet parameters.
Connection Type
Description
PPPoE (PPP over Ethernet)
If your internet service provider (ISP) provides a user name
and password to you for internet access, your connection
type may be PPPoE or PPPoA, contact your ISP for details.
PPPoA (PPP over ATM)
IPoE (IP over
Ethernet)
Dynamic IP
Select thus type if your ISP does not provide any parameters
to you for internet access.
Static IP
If your internet service provider provides a static IP address
and other related information to you for internet access, your
connection type may be IPoE or IPoA, contact your ISP for
details.
IPoA (IP over
ATM)
Static IP
Bridge
Select thus type when this device only serves as a modem,
and you want to set up a dial-up connection or enter other
internet parameters directly on your computer for internet
access.
Step 4 Country/Region: Select your country or region.
Step 5 ISP: Select your internet service provider.
Step 6 Enter the related internet parameters provided by your ISP.
Step 7 Click OK on the bottom of the page to apply the settings.
--End
If your country/region and ISP are not covered in the drop-down list, select Other, and enter the VPI
and VCI manually. If you do not know the VPI and VCI, contact your ISP for help.
2.4.2 Ethernet Cable Connection
If you connect the modem router to the internet via an Ethernet cable, refer to the configuration in this part to
complete your internet settings. In this case, this device only serves as a wireless router.

Tenda V300 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	64-bit WEP, 128-bit WEP, SNMP, SSID, WDS, WPA-PSK, WPA2-PSK, WPS
Supported network protocols	G.994, ANSI T1.413 2, ITU-T G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.992.3 (G.dmt.bis) Annex A/L/M, ITU-T G.992.5 Annex A, G.993.2 (VDSL2), G.993.5, G.993.2 Amd 7 (ToD), G.998.4 (G.inp), ATM, PTM
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	20 dBmW
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	White
LED indicators	DSL, LAN, Power, USB, WAN, WLAN, WPS
Antenna gain level (max)	5 dBi

Weight and Dimensions

Depth	105.2 mm
Width	157.8 mm
Height	29.4 mm
