Tenda V300 User Manual

88
 If you create many groups, the LAN IP address used by the Default group members is 192.168.1.1,
the LAN IP address of the second group member is 192.168.2.1, and the following groups follow
the same rule.
 If the IPTV function is enabled, the modem router automatically creates one interface group
named IPTV. If it is deleted, the IPTV function is not available.
4.18 IP Tunnel
An IP tunnel is an Internet Protocol (IP) network communications channel between two networks. It is used to
transport another network protocol by encapsulation of its packets.
The modem router provides two IP tunnels: IPv6inIPv4 and IPv4inIPv6.
4.18.1 IPv6inIPv4
IPv6inIPv4 is an internet transition mechanism for migrating from Internet Protocol version 4 (IPv4) to IPv6.
IPv6inIPv4 uses tunneling to encapsulate IPv6 traffic over explicitly-configured IPv4 links.
Choose Advanced > Advanced Setup > IP Tunnel > IPv6inIPv4 to enter the configuration page.
To configure the IPv6inIPv4 tunnel, perform the following procedure:

Tenda V300 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	64-bit WEP, 128-bit WEP, SNMP, SSID, WDS, WPA-PSK, WPA2-PSK, WPS
Supported network protocols	G.994, ANSI T1.413 2, ITU-T G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.992.3 (G.dmt.bis) Annex A/L/M, ITU-T G.992.5 Annex A, G.993.2 (VDSL2), G.993.5, G.993.2 Amd 7 (ToD), G.998.4 (G.inp), ATM, PTM
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	20 dBmW
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	White
LED indicators	DSL, LAN, Power, USB, WAN, WLAN, WPS
Antenna gain level (max)	5 dBi

Weight and Dimensions

Depth	105.2 mm
Width	157.8 mm
Height	29.4 mm
