Tenda V300 User Manual

51
time.
Prefix
Specify the prefix.
Preferred Life Time
(hour)
Specify the preferred life time in hour.
Valid Life Time (hour)
Specify the valid life time in hour.
Enable MLD Snooping
MLD is used by IPv6 routers for discovering multicast listeners on a directly attached
link. If disabled on layer2 devices, IPv6 multicast data packets will be broadcast on the
entire layer2; if enabled, these packets will be multicast to only specified recipient
instead of being broadcast on the entire layer2.
4.6 NAT
4.6.1 Virtual Server
If computers are connected to the modem router to form a LAN and access the internet through the modem
router, internet users cannot access the hosts on the LAN. Therefore, the servers, such as web servers, email
servers, and FTP servers, on the LAN are inaccessible to internet users. To enable internet users to access a LAN
server, enable the virtual server function of the modem router, and map one service port of the virtual server to
the IP address of the LAN server. This enables the modem router to forward the requests arriving at the port
from the internet to the LAN server.
Choose Advanced> Advanced Setup > NAT > Virtual Server to enter the configuration page.
Click Add to configure the function.

Tenda V300 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	64-bit WEP, 128-bit WEP, SNMP, SSID, WDS, WPA-PSK, WPA2-PSK, WPS
Supported network protocols	G.994, ANSI T1.413 2, ITU-T G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.992.3 (G.dmt.bis) Annex A/L/M, ITU-T G.992.5 Annex A, G.993.2 (VDSL2), G.993.5, G.993.2 Amd 7 (ToD), G.998.4 (G.inp), ATM, PTM
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	20 dBmW
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	White
LED indicators	DSL, LAN, Power, USB, WAN, WLAN, WPS
Antenna gain level (max)	5 dBi

Weight and Dimensions

Depth	105.2 mm
Width	157.8 mm
Height	29.4 mm
