Tenda V300 User Manual

76
Parameter
Description
G.Dmt
It specifies G992.1. The maximum uploading/downloading rate is 1.3 Mbps/8 Mbps.
When it is used, POTS splitter is required for client.
G.lite
It specifies G992.2. The maximum uploading/downloading rate is 512 Kbps/1.5 Mbps.
When it is used, POTS splitter is NOT required for client.
T1.413
It specifies ANSI_T1.413. Based on DMT standard, the maximum
uploading/downloading rate is 1.5 Mbps/15 Mbps. When it is used, POTS splitter is
required for client.
ADSL2
It specifies G992.3. The maximum uploading/downloading rate is 1 Mbps/12 Mbps.
AnnexL
Reach Extended ADSL2. When the clients are far away from the modem router, this
mode can improve the coverage. The maximum uploading/downloading rate is 1.5
Mbps/15 Mbps.
ADSL2+
It specifies G992.5. The maximum uploading/downloading rate is 1 Mbps/24 Mbps.
AnnexM
Compatible with the upstreaming bandwidth extension mode, and based on G992.3
ADSL2 and G992.5 ADSL2+, the uploading rate of this mode increases to 2Mbps for
ADSL2+ from 1 Mbps for ADSL2. AnnexM takes effect only when ADSL2, AnnexL or
ADSL2+ is selected.
4.15 DLNA
DLNA is a solution to share multimedia resources among digital devices by wired or wireless means. For example,
you can use the mobile phone and the DLNA controller to enable your TV or computer to play the video and

Tenda V300 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cables included	LAN (RJ-45), Phone (RJ-11)
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	64-bit WEP, 128-bit WEP, SNMP, SSID, WDS, WPA-PSK, WPA2-PSK, WPS
Supported network protocols	G.994, ANSI T1.413 2, ITU-T G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.992.3 (G.dmt.bis) Annex A/L/M, ITU-T G.992.5 Annex A, G.993.2 (VDSL2), G.993.5, G.993.2 Amd 7 (ToD), G.998.4 (G.inp), ATM, PTM
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	20 dBmW
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	White
LED indicators	DSL, LAN, Power, USB, WAN, WLAN, WPS
Antenna gain level (max)	5 dBi

Weight and Dimensions

Depth	105.2 mm
Width	157.8 mm
Height	29.4 mm
