8.8 APPENDIX D - Setting table
Note The 26 element, the output relay and LEDs K7...K10, L6...L10 and the binary input IN3...IN42 settings are available only when the concerning I/O
circuits are implemented (MPT, MRI and MID16 modules on Thybus)
Description Parameter Unit Setting range
Set
Base
Relay reference name
Relay nominal frequency - fn Hz 50 ... 60 step = 10
Relay phase nominal current side H - InH 1 A | 5 A
Phase CT primary nominal current side H - InpH A
1 ... 499 step = 1
500 ... 4990 step = 10
5000 ... 20000 step = 100
Relay phase nominal current side L - InL 1 A | 5 A
Phase CT primary nominal current side L - InpL A
1 ... 499 step = 1
500 ... 4990 step = 10
5000 ... 20000 step = 100
Relay residual current - IEn 1 A | 5 A
Residual CT primary nominal current - IEnp A
1 ... 499 step = 1
500 ... 4990 step = 10
5000 ... 20000 step = 100
Protected device nominal current - Ing A
1 ... 499 step = 1
500 ... 4990 step = 10
5000 ... 20000 step = 100
Primary nominal current chosen as reference - Inref A 0 ... 0 step = 0
Side reference for compensation - RefSide H | L | T
Current matching type - MatchType INTERNAL | EXTERNAL
Measurements reading mode RELATIVE | PRIMARY | PROTECTED DEVICE
Language English | Turkish | Russian
Input sequence
Polarity
Inputs
Binary input IN1
IN1
Logic Active-ON | Active-OFF
IN1 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN1 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN1 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | H-L-87GML Block1 |
H Block1 | L Block1 | 87GML Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN2
IN2
Logic Active-ON | Active-OFF
IN2 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN2 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
