TECHNICAL DATA
20
NG10 - Manual - 04 - 2022
 Oscillography (DFR)
[1]
Format COMTRADE
Recording mode
circular
Sampling rate
16 samples / cycle
Trigger setup:
• Pre-trigger time
0.05...1.00 s (step 0.01 s)
• Post-trigger time
0.05...60.00 s (step 0.05 s)
Set sample channels:
i
L1H
, i
L2H
, i
L3H
, i
L1L
, i
L2L
, i
L3L
, i
E
, i
L1cH
,
i
L2cH
, i
L3cH
, i
L1cL
, i
L2cL
,
i
L3cL
, i
SL1
, i
SL2
, i
SL3
, i
dL1
, i
dL2
, i
dL3
,
Set analog channels:
Analog 1...Analog 12 I
L1H
, I
L2H
, I
L3H
, I
L1L
, I
L2L
, I
L3L
,
I
E
, I
L1cH
, I
L2cH
, I
L3cH
, I
L1cL
, I
L2cL
,
I
L3cL
, I
SL1
, I
SL2
, I
SL3
, I
dL1
, I
dL2
, I
dL3
,
I
E
, I
ESH
,T1...T8
[2]
Set digital channels:
Digital 1...Digital 16 K1... K6, K7...K10,
IN1, IN2, IN3...IN42
[3]
Set digital channels from 87G-M-L states
(Digital 17...32)
• Start states ST Id>-L1...L3, ST Id>>-L1...L3, ST
2nd-REST, ST 5th-REST, ST H-REST-L1...
L3, ST satDet
• Trip states TR Id>-L1...L3, TR Id>>-L1...L3
 PLC (Programmable Logic Controller)
[4]
Reference standard IEC 61131-3
Language
[5]
IL (Instruction List)
Inputs:
Binary inputs IN1, IN2 on board
IN8...IN10 with MRI module
IN11...IN26 with one MID16 module
IN27...IN42 with two MID16 modules
Delayed binary inputs
[6]
IN1, IN2 on board
IN8...IN10 with MRI module
IN11...IN26 with one MID16 module
IN27...IN42 with two MID16 modules
Start (all elements) Start U<, Start U<<,...etc
Trip (all elements) Trip U<, Trip U<<,...etc
Measures IL1, IL2,...ecc
Temperature Pt100
Block inputs BLK2IN-Iph, BLK2IN-IE,...etc
Outputs:
Relays K11...K6 on board
K7...K10 with MRI module
LEDs START, TRIP, L1...L6 on board
L7...L10 with MRI module
Block outputs BLK2OUT-Iph, BLK2OUT-IE,...etc
Current converter DAC
Note 1 For the DFR function a licence is required; call Thytronic for purchasing.
Note 2 The measures of temperature are available only when the MPT module on Thybus is enabled (eigth Pt100 inputs)
Note 3 Output relay K7...K10 and binary input IN3...IN42 states are available only when the concerning I/O circuits are implemented (MRI and MID16
modules on Thybus)
Note 4 For the PLC function a licence is required; call Thytronic for purchasing.
Note5 With ThyVisor V3.4.3 release and compiler IEC 61131-3 V1.2.7 only the IL language is implemented (Instruction List);
other languages, according with IEC 61131 standard (ST (Structured Text)), LD (Ladder Diagram), FBD (Function Block Diagram), SFC (Sequential
Functional Chart), will be available soon
Note 6 The input state is acquired downstream the t
ON
and t
OFF
timers
