Servicing the Battery
Note: Keep the terminals and the entire battery case clean because a dirty battery will
discharge slowly.
1. Prepare the machine for maintenance.
2. Open the screen.
3. Check the condition of the battery.
Note: Replace a worn or damaged battery.
4. Disconnect the battery cables, and remove the battery from the machine.
5. Clean the entire battery case with a solution of sodium bicarbonate (baking soda) and
water.
6. Rinse the case with clean water.
7. Assemble the battery to the machine and connect the battery cables.
8. Close and latch the screen.
Replacing a 12 V Fuse-Block Fuse
The fuse block is under the seat.
G437962
1. Prepare the machine for maintenance.
2. Unlatch and tilt the seat.
3. Replace the open fuse with the same fuse type
and amperage rating.
4. Close and latch the seat.
Replacing the TEC Fuse
1. Prepare the machine for maintenance.
2. Unlatch and open the hood.
3464-482A Page 6–25 Maintenance: Electrical System Maintenance
