Hauling the Machine
Follow the tips below when hauling the machine.
• Use full-width ramps for loading the machine onto a trailer or truck.
• Tie the machine down securely.
Pushing or Towing the Machine
In an emergency, you can move the machine forward by actuating the bypass valve in the
variable-displacement hydraulic pump and pushing or towing the machine.
IMPORTANT
Do not push or tow the machine faster than 3 to 4.8 km/h (2 to 3 mph). If you push or
tow at a faster speed, internal transmission damage may occur.
The bypass valves must be open and the brake released whenever you push or tow
the machine.
1. Unlatch the seat base and tilt the seat open.
2. Locate the bypass valves under the seat and on the top of the hydrostat.
G439099
3. Loosen the valves with 3 turns to allow the oil to bypass internally.
3464-482A Page 5–35 Operation: Hauling the Machine
