Changing the Hydraulic Fluid (continued)
G439327
Manifold
Loosen fitting here
90° fitting
3. Disconnect the 90° fitting from the manifold and allow the tank to drain.
4. When hydraulic fluid stops draining from the tank, connect the 90° fitting to the manifold.
5. Fill the tank with the specified hydraulic fluid.
IMPORTANT
Use only the hydraulic fluids specified. Other fluids could cause system damage.
6. Install the tank cap.
7. Start the engine, and use all the hydraulic controls to distribute hydraulic fluid throughout
the system.
8. Check for hydraulic-fluid leaks.
9. Check the level.
Cutting Unit Maintenance
Checking the Reel-to-Bedknife Contact
Check the reel-to-bedknife contact even if the quality of cut had been acceptable previously.
Note: There must be light contact across the full length of the reel and bedknife.
Maintenance: Cutting Unit Maintenance Page 6–38 3464-482 A
