Toro 03672 User Manual

5
Installing the CE Hood Lock
Parts Required
1 Hood lock
1 Seal
1 Jam nut
1 Washer
G439569
1. Raise the hood.
2. Remove the rubber grommet
from the hole
in the left side of the hood.
G445763
3. Ensure that the seal is assembled to the
hood lock
.
4. Remove the nut
from the lock.
5. Outside the hood, insert the hook end of the
latch through the hole in the hood.
Note: The seal is aligned to the outside of the
hood.
6. Inside the hood, secure the lock to the hood
with the washer
and nut.
7. Close the hood, and use the enclosed hood-
lock key to check that the hook of the lock
engages the frame catch when locked.
3464-482A Page 3–13 Setup: Installing the CE Hood Lock
