TorsionAxleAssembly
g241362
Figure9
1.Flangeheadbolt(6each)4.Nut(4each)
7.Flapbracket
2.Rubberap5.Nut(6each)
3.Flangeheadbolt(4each)
6.T orsionaxle
Replacementtorsionaxleassembliesaresuppliedwithnewwheelhub
assembliesalreadyinstalled.
RemovingtheTorsionAxleAssembly
Note:RefertoFigure9duringthisprocedure.
1.Parkthemachineonalevelsurface,lowerthecuttingunitsanddisengage
thePTO.Removethemaindriveshaftanddisconnectthemachine
fromthetowvehicle.Securethemachinewithtowbarjack;refertothe
Groundsmaster1200Operator’sManual.
2.Blockthewheelthatyouarenotremovingwithchockstopreventthe
machinefrommoving.
3.Liftthemachinefromthegroundandsupporttheraisedmachinewithajack
stand;refertoGroundsmaster1200Operator’sManual.
4.Removethewheel;refertoRemovingtheWheel(page3–3).
Chassis:ServiceandRepairs
Page3–8
Groundsmaster®1200Pull-BehindRotaryMower
18235SLRevA
