CuttingUnitDriveShafts
g241350
Figure33
1.Cuttingunitgearbox3.Cuttingunitdriveshaft
2.Quickreleasepin4.Centergearbox
RemovingtheCuttingUnitDriveShafts
1.Parkthemachineonalevelsurface,lowerthecuttingunitsanddisengage
thePTO.Removethemaindriveshaftanddisconnectthemachine
fromthetowvehicle.Securethemachinewithtowbarjack;refertothe
Groundsmaster1200Operator’sManual.
WARNING
Supportthedriveshaft(weighsapproximately16Kg(36lb))to
preventitfromdroppingandcausingpersonalinjurywhenremoving.
Groundsmaster®1200Pull-BehindRotaryMower
Page5–5
CuttingUnitDrive:ServiceandRepairs
18235SLRevA
