Cleaning the Engine Cooling System (continued)
3. Thoroughly clean all debris out of the engine area.
4. Close and latch the hood.
G416241
5. Release the rear screen latches and pivot
the rear screen
open.
6. Thoroughly clean the screen with compressed
air.
G416242
7. Rotate the 2 oil-cooler latches inward, and
tilt the oil cooler
.
G416243
8. Thoroughly clean both sides of the oil cooler
and the radiator
with compressed air.
9. Raise the oil cooler and secure it with the 2
latches.
10. Close and latch the screen.
Maintenance: Cooling System Maintenance Page 6–35 3464-478 A
