Fuel
Gauge
The
fuel
gauge
(
Figure
9
)
is
located
on
the
fuel
tank
next
to
the
ller
cap,
at
the
left
side
of
the
machine.
The
gauge
displays
the
amount
of
fuel
in
the
tank.
g008398
Figure
9
1.
Empty
4.
Fuel
gauge
2.
Full
5.
Fuel-tank
cap
3.
Needle
Passenger
Handholds
The
passenger
handholds
are
located
on
the
right
side
of
the
dash
panel
and
at
the
outside
of
each
seat
(
Figure
10
).
g009193
Figure
10
1.
Handhold—hip
restraint
2.
Passenger
handhold
15
14
16
