TV back panel controls and connections
For explanations of cable types and connections, see “Connecting Your
TV” on page 26.
HDMI IN
4
ANT/CABLE
LAN
FIXED
AUDIO
IR
OUT
PC / HDMI 2
AUDIO
OUTOUT
PC IN
COLOR STREAM HD / VIDEO 2 IN
R
IN
AUDIO L / MONO
P
R
P
B
Y / VIDEO
POWER button
Volume up
Volume down
Switches the function of VOL+/-
buttons to select volume, channel, or
input mode.
HDMI
®
IN port
PC / HDMI
®
Audio IN
IR Blaster OUT
LAN
Analog Audio OUT
PC IN
Antenna / Cable
Colorstream
®
HD /
Video 2 IN
