28
Connecting Your TV
Optical audio cable
(Sample Illustration) Optical audio cable
Optical audio cable connects receivers with Dolby
®
Digital or PCM
(pulse-code modulation) optical audio input to the TV’s Digital Audio
Out terminal, see “Connecting a digital audio system” on page 35.
Analog RGB (15-pin) computer cable
(Sample Illustration) Analog RGB (15-pin) computer cable
Analog RGB (15-pin) computer cable connects a computer to the to the
TV’s PC IN terminal, see “Connecting a computer to the TV’s PC IN
terminal:” on page 40.
NOTE
Separate audio cables are required.
3.5mm Stereo to RCA Y-cable
(Sample Illustration) 3.5mm Stereo to RCA Y- cable
3.5mm Stereo to RCA Y-cable connects an audio signal from DVI device
to TV.
Overview of cable types
