Toshiba e-studio2007 User Manual

5 VARIOUS FUNCTIONS
128 Network Menu List
How the TCP/IP protocol must be set depends on your network environment.
Use the digital keys to enter [IP ADDRESS] or [SUBNET MASK] or [DEFAULT GATEWAY].
For entering characters, see the following page.
 P.120 “Character entry”
 Setting the HTTP network service
You can enable or disable the HTTP network server service that provides web-based utilities on this equipment, such as
TopAccess.
Use the digital keys to enter [PRIMARY PORT NUMBER].
For entering characters, see the following page.
 P.120 “Character entry”
Item name Description
ADDRESS MODE  STATIC IP (When connecting to a local area network using static IP addresses)
Select [STATIC IP] and specify an IP address when connecting to a local area network where static IP
addresses are used. Also set the subnet mask and default gateway as required.
 DYNAMIC (When TCP/IP is set by Auto-IP addressing or DHCP server)
Select [DYNAMIC] when you do not know the TCP/IP settings that should be assigned to the
equipment. If [DYNAMIC] is selected when your network supports the DHCP, the IP address, subnet
mask, default gateway, primary WINS server address, secondary WINS server address, POP3 server
address, and SMTP server address are acquired from the DHCP server. If the DHCP is not supported,
an appropriate IP address is assigned to this equipment by the auto-IP addressing function. However,
the auto-IP addressing may not work properly if a router is placed in the network.
 NO AUTO IP (When TCP/IP is set using only the DHCP server)
Select [NO AUTO IP] when the equipment is connected to a local area network with a DHCP server
and you want to set the TCP/IP not using the auto-IP addressing function, but only the DHCP. When
[NO AUTO IP] is selected, the IP address, subnet mask, default gateway, primary WINS server
address, secondary WINS server address, POP3 server address, and SMTP server address are
acquired from the DHCP server, and the IP address assignment by the auto-IP addressing function
disabled.
IP ADDRESS
SUBNET MASK
DEFAULT GATEWAY
Press [IP ADDRESS] and enter the IP address of this equipment using the digital keys.
Enter the subnet mask and default gateway as required.
Use or to switch the active box.
This item is enabled only when [STATIC IP] is selected for [ADDRESS MODE].
TCP/IP
ADDRESS MODE
IP ADDRESS
SUBNET MASK
Item name Description
HTTP SERVER  ENABLE — Press this button to use the HTTP network server service.
 DISABLE — Press this button to disable the HTTP network server service.
This option must be enabled for TopAccess.
PRIMARY PORT NUMBER Press this button to enter the primary port number to be used for receiving HTTP access
from other clients. Normally use the default port number “80”.
HTTP
HTTP SERVER
PRIMARY PORT NUMBER
