Toshiba Tosvert VF-S15 User Manual

E6582175
F-2
6
6.1 Parameters useful for settings and adjustments
6.1.1 Searching for changes using the history function (auh)
auh : History function
History function (auh):
Automatically searches for 5 latest parameters that are programmed with values different from the
default setting and displays them in the auh. Parameter setting can also be changed within this
group auh.
How to use the history function
Operation panel
action
LED display Operation
00
Displays the output frequency (operation stopped).
(When standard monitor display selection f710=0
[output frequency])
auh
The first basic parameter “auh” (history function) is displayed.
acc
The parameter that was set or changed last is displayed.
80
Press the center of the setting dial to display the set value.
50
Turn the setting dial to change the set value.
50 acc
Press the center of the setting dial to save the changed value. The
parameter name and the programmed value will flash on and off
alternately.
****
Turn the dial as described above to search for and display changed
parameters to check and change the settings.
head
(end)
head: First historic record
end: Last historic record
Parameter
display

auh

frf

00
Press the MODE key to return to the parameter setting mode
“auh.”
After that you can press the MODE key to return to the status
monitor mode or the standard monitor mode (display of output
frequency).
Notes on operation
 If no history information is stored, this parameter is skipped and the next parameter “aua” is displayed.
 head and end are added respectively to the first and last parameters in a history of changes.
MODE
MODE
MODE
MODE
