E6582175
D-7
4
How to set extended parameters
Each extended parameter is composed of an "f, a or c "suffixed with a 3-digit figure, so first select and read out
the heading of the parameter you want "f1" to "f9", "a", "c" ("f1": Parameter starting
point is 100, "a": Parameter starting point is A.)
(5) Select the title of the parameter you want to change. (Turn the setting dial.)
(6) Read the extended parameter. (Press the center of the setting dial.)
(7) Select parameter to be changed. (Turn the setting dial.)
(8) Read the programmed parameter setting. (Press the center of the setting dial.)
(9) Change the parameter value. (Turn the setting dial.)
(10) Press this key to save the parameter value. (Press the center of the setting dial.)
4.3 Functions useful in searching for a parameter or
changing a parameter setting
This section explains functions useful in searching for a parameter or changing a parameter setting.
Changed parameters history search (History function) auh
This function automatically searches for the last five parameters whose settings have been changed. To use this
function, select the auh parameter. (The changed parameters are displayed regardless of difference with the
default settings.)
The parameters set by communication option or RS485 communication are not searched and not displayed.
Refer to section 6.1.1 for details.
Easy setting parameters according to application (Application easy setting) aua
The necessary parameter for your machine can be easily set.
Select the machine by parameter aua and set by using the easy setting mode.
Refer to section 6.1.2 for details.
Adjustment range and display of parameter setting value
h1:An attempt has been made to assign a value that is higher than the programmable range.
lo: An attempt has been made to assign a value that is lower than the programmable range.
If the above alarm is flashing on and off, values that exceed h1 or are equal or lower than lo cannot be set.
* A setting value of the presently-selected parameter might exceed the upper limit or the lower limit by changing other
parameters.
To Next Page
