E6582175
A-2
1
1.2 Contents of the product
Explanation of the name plate label
Note 1) Always shut power off first then check the ratings label of inverter held in a cabinet.
Note 2) ID label is stuck for special specification product.
Model name
TOSVERT
VF-S15 series
Number of power
phases
S : single-phase
None: three-phase
Applicable motor
capacity
002 : 0.2kW
004 : 0.4kW
007 : 0.75kW
015 : 1.5kW
022 : 2.2kW
037 : 4.0kW
055 : 5.5kW
075 : 7.5kW
110 : 11kW
150 : 15kW
Additional functions I
L : Built-in high-attenuation
EMC filter
M: Built-in basic filter
Operation panel
P: Provided
Input (AC) voltage
2 : 200V to 240V
4 : 380V to 500V
Additional functions II
W1 : World model
None: Japanese model
V F S 1 5 S
-
2 0 0 7 P L - W 1
Type Form
Quick start manual
Danger label kit
CD-ROM
Contains the instruction manual in
digital form
DANGER
DANGER
DANGER
DANGER
Risk of injury, electric shock or fire.
Read the instruction manual.
Do not open the cover while power is applied
or for 15 minutes after power has been removed.
Ensure proper earth connection.
WARNING
Risk of injury, electric shock or fire.
Read the instruction manual. Ensure proper earth connection.
Do not open the cover while power is applied
or for 15 minutes after power has been removed.
WARNUNG
Risk of injury, electric shock or fire.
Read the instruction manual. Ensure proper earth connection.
Do not open the cover while power is applied
or for 15 minutes after power has been removed.
AVVERTENZA
Risk of injury, electric shock or fire.
Read the instruction manual. Ensure proper earth connection.
Do not open the cover while power is applied
or for 15 minutes after power has been removed.
ADVERTENCIA
Risk of injury, electric shock or fire.
Read the instruction manual. Ensure proper earth connection.
Do not open the cover while power is applied
or for 15 minutes after power has been removed.
⼊ޓ๔
DANGER
DANGER
Risk of injury, electric shock or fire.
Read the instruction manual. Ensure proper earth connection.
Do not open the cover while power is applied
or for 15 minutes after power has been removed.
AVERTISSEMENT
Risque de blessure, d’électrocution ou d’incendie.
Lire le manuel d’instruction.
Avant d’intervenir dans le variateur couper la puissance
et attendre 15 minutes avant d’ouvrir le couvercle.
Assurer un raccordement approprié
à
la terre.
・English
・ Germany / English
・ Italian / English
・ Spanish / English
・ Chinese / English
・ France / English
Danger labels for sticking in 6 languages.
This instruction manual is for the “Ver. 120” CPU version of the inverter.
The function in this manual may not be partially realized in the previous CPU version.
Please be informed that CPU version will be frequently upgraded.
