CNT-SVP01C-EN 103
Chapter 9
Implementing a graphical
program
Before downloading a program to the Tracer MP580/581, you must com-
pile the program. When you compile, the TGP editor checks the program
for errors and prepares it for download. You can upload and download
compiled programs, and you can view the status of downloaded programs
in the controller.
Compiling a program
To compile a program:
X From the Program menu, choose Build/Compile. The system builds
and compiles the program. The output window displays the results,
including any applicable errors.
Downloading a program
To download a program to the Tracer MP580/581 controller:
1. Compile the program you want to download if you have not done so
already.
2. From the Program menu, choose Download to MP580. The Security
Logon dialog box appears.
3. Type in your user name and password and click OK.
4. From the Download to MP580 menu, choose one of the following
options:
• New, if the program is new. The program download begins. Upon
completion of the download, a message appears stating that the
program downloaded successfully. Go to step 7.
• Replace Existing, if the program already exists in the controller.
The Select a Program dialog box appears. Go to step 5.
5. Click the program name you want to replace.
6. Click OK. The program downloads. Upon completion of the download,
a message appears stating that the program was overwritten success-
fully.
7. Click OK.
