Standard toolbar
Use the Standard toolbar buttons (Figure 45) to open a new or existing
program file or to save a file. Click one of the edit buttons to cut, copy,
paste, or delete a block or group of blocks. You can undo or redo the last
action completed in the editor, add a wired or wireless connection, or print
the program. Click the Help button and then click on a block in the design
space to get information about that block.
Figure 45. Standard toolbar
Alignment toolbar
Select the blocks in the design space you want to align and click an align-
ment button (Figure 46) to align the blocks in the design space. The last
block selected controls the alignment.
Figure 46. Alignment toolbar
New
Open
Save
Print
Cut
Copy
Paste
Undo
Redo
Delete
Select
Wire
Comment
Wireless
Connection
Help
Left Alignment
Right Alignment
Bottom Alignment
Top AlignmentTop Alignment
