UNT-SVX07B-EN 71
Controls Interface
Configuring the Wireless Display Sensor (Model WDS only)
Note: Sensors shipped with the fan-coil are pre-configured for three speeds.
The configuration of the sensor determines which system features can be accessed and changes
can be made by the tenant (for example, changes to cooling/heating mode, setpoint, or fan speed.
Verify system and associated unit features before configuring the sensor.
The building owner or operator may choose to limit tenant access to certain features. This can be
done through configuration. Or, if a sensor is configured to match all control capabilities of the
building automation system, the locking feature can be used to restrict the tenant from making
changes.
Configuration Procedure
To configure settings on the model WDS sensor, follow this procedure in the order presented.
1. Press the configuration button for 3 seconds.
LED1
LED2
LED3
LED5
Model WTS sensor
Model WDS sensor
Test button
Push firmly,
then release
Push firmly,
then release
Test button
To Next Page
