VAT 653 Series User Manual

Series 65 SPARE PARTS
963283EA Edition 2019-05-03 125/
129
All “Item“ refer to chapter «Drawing»
12.1.1 Valve unit with seals and grease
Item Description
Valve size
Valve part number
DN100
65340 - . . . . - . . . .
DN160
65344 - . . . . - . . . .
DN200
65346- . . . . - . . . .
DN250
65348 - . . . . - . . . .
1
Bonnet
seal
Viton N-5100-259 N-5100-267 N-5100-272 N-5100-277
other materials on request on request on request on request
2 Body seal (Viton)
This includes a 2ml syringe
of vacuum grease
204884 206527 200468 202592
3
Gate
seal
Viton N-5100-155 N-5100-258 N-5100-266 N-5100-275
other materials on request on request on request on request
Seal kit vacuum (Viton).
This consists of item 2 and
3.
204883 206526 204204 203883
Syringe of
vacuum grease
2ml 206792
5ml 206793
4
Actuator shaft seals (Viton)
Actuator compressed air
gasket
N-5100-326
(2 pcs required per valve)
927458
5
Sealing ring shaft seals
(Viton)
N-5111-112
(12 pcs required
per valve)
N-5111-112
(12 pcs required
per valve)
N-5111-112
(16 pcs required
per valve)
N-5111-112
(16 pcs required
per valve)
6
Pendulum plate:
- Blank B1 *) on request on request on request on request
- Blank B2 *) on request on request on request on request
- Hardanodized B1 *) on request on request on request on request
- Hardanodized B2 *) on request on request on request on request
- Nickel coated B1 *) on request on request on request on request
- Nickel coated B2 *) on request on request on request on request
7
Sealing ring
- Blank on request on request on request on request
- Hardanodized on request on request on request on request
- Nickel coated on request on request on request on request
8 Actuator
B1 *) on request 342943
B2 *) on request on request
*) Refer to figures on next page to check for actuator position options.
