VAT 653 Series User Manual

INSTALLATION Series
65
94/129 Edition 2019-05-03 963283EA
4.12.4 Sensor delay command (PM-V2 compatible)
Description Commands Acknowledgements Examples / Explanation
t:abcdefg t:
t:4000000
a = Response Time 0 = 0 ms
1 = 20 ms
2 = 40 ms
3 = 60 ms
4 = 80 ms
5 = 100 ms
6 = 150 ms
7 = 200 ms
8 = 250 ms
9 = 300 ms
A = 350 ms
B = 400 ms
C = 500 ms
D = 600 ms
E = 800 ms
F = 1000 ms
4 = Sensor response time 80 ms
bcdefg = Reserved 000000 Use 000000 only
4.12.5 Error messages (PM-V2 compatible)
Error messages Description
E:000001 Parity error
E:000002 <CR> or <LF> is missing
E:000003 «:» is missing
E:000004 Wrong letter code
E:000005 Numerical value not given in 6 digits
E:000006 Numerical value larger 1000
E:000007
PRESSURE MODE, ZERO or LEARN have been selected with no sensor connected (display format set for no sensor)
E:000008 Controller is not in correct mode for the given command (e.g. L:XXXXXX given while a logic input is activated)
E:000009
Valve is not able to execute the command (e.g. the valve is in error state)
E:000200 Error with ZERO
- valve is not in open position
- PM controller is switched in control mode PRESSURE MODE
- function ZERO blocked (= DISABLED)
E:000201 Sensor with the higher full scale: if zero offset is higher than +/- 1.4 V
E:000202 Sensor with the lower full scale: if zero offset is higher than +/- 1.4 V
(this error message is not active when only one sensor is connected)
E:000203 Sensor setup error
The full scale ratio Sensor 1 / Sensor 2 is either >100 or <= 1
E:000204 Commands U:19 or U:20 sent with one or no sensor connected
