VAT 653 Series User Manual

Series 65 INSTALLATION
963283EA Edition 2019-05-03 43/
129
“close”.
Delay
After this delay the power failure reaction starts after the power failed
Parameter location:
CPA RS232
Power Fail Option Refer to RS232-setup command for detail
4.6.3 Digital I/O
On the power connecter there are two digital inputs and two digital outputs available.
See chapter «Power and sensor connection» to get more information about the pinning.
Each of the four IO (2 inputs and 2 outputs) has following parameters:
Parameter Description
Enable
‘True’ enables the input or output
State
Current state of the input or output
Functionality
Defines the functionality of the input or output
Inverted
‘True’ inverts the input or output. In case of an input, an inversion means
that a ‘0’ activate (State gets 1) the functionality and a ‘1’ means not
activated (State gets 0)
Parameter location:
CPA RS232
Power Connector IO Refer to RS232-setup command for detail
