15 - Chain tensioner, 50 Nm
❑ for camshaft timing chain
❑ Only rotate engine when chain tensioner is installed.
16 - Cover
❑ Can be removed and installed with engine installed.
❑ Coat sealing surface with sealant - D 176 501 A1- .
17 - Sealing ring
❑ For camshaft control valve 1 - N205- and exhaust camshaft control valve 1 - N318-
❑ Renew if damaged or leaking
❑ Installing ⇒ page 78
18 - 8 Nm
19 - 8 Nm
20 - Coolant pipe
❑ With retaining clips for vacuum pipe
21 - 23 Nm
22 - Slide rail
❑ for camshaft timing chain
23 - 23 Nm
❑ Insert with locking fluid - D 000 600 A2-
24 - Union
❑ Bolt on before assembling cylinder head
25 - O-ring
❑ Renew
26 - Sealing ring
❑ Renew
27 - Cylinder head gasket
❑ Metal gasket.
❑ Renew
❑ Renew cylinder head gasket ⇒ page 60 .
❑ After renewing, renew entire coolant.
28 - Cylinder head
❑ Check for distortion ⇒ page 60 .
❑ Removing and installing ⇒ page 60
❑ After renewing, renew entire coolant.
29 - Cylinder head bolt
❑ Renew
❑ Coat bolt with locking fluid - D 197 300 A2- before installing ⇒ page 67 .
❑ Follow assembly instructions and note sequence when undoing ⇒ page 65
❑ Follow assembly instructions and note sequence when tightening ⇒ page 67
CC 2012 ➤ , Passat 2011 ➤ , Passat Variant 2011 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 06.2019
1. Cylinder head 59
