Note
♦ The hoses of the air conditioner compressor can remain con‐
nected.
♦ Suspend the air conditioner compressor -3- using a piece of
wire -1- at a suitable position under the vehicle until it is ready
to be reinstalled.
♦ Ensure that the hoses -2- are not stretched or kinked when
doing this.
– Remove the two lower bolts -arrows- of alternator -C- from
below.
– Release and disconnect connector -2-.
– Remove the two bolts -arrows- of alternator -C- .
– Swing alternator -C- slightly to the left to gain access to con‐
nections on generator side.
– Release and disconnect DF wire connector -1-.
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
162 Rep. gr.27 - Starter, current supply, CCS
