Assigning the sender holder to location on inside of front bumper
cover, from model year 2011:
A - left centre (in radiator grille)
B - right centre (in radiator grille)
C - right outer
D - left outer
Note
♦ When mounting the sender, make sure that the isolation ring
is correctly mounted on the sender head and does not ride or
roll up on insertion into the sender holder.
♦ Both locking lugs of sender holder must audibly engage when
installing the sender.
– After installing the sender, check that the sender is correctly
seated in the bracket. Visible on the outer side of the bumper,
dimension -a- of the ring gap between the sender head and
bumper cover must be even all around.
14.11 Bonding sender holder in bumper cover
14.11.1 Bonding sender holder in bumper cover
The bonding process for the sender retainers in the front and rear
bumper covers is performed in the same manner. The bonding
area on the inside of the bumper cover is marked as a field around
the punched hole to assist in aligning the sender retainer during
the bonding process. Ensure that the material temperature of the
bumper cover and the sender holder lies between 15 ? and 25 ?.
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
14. Parking aid 347
