– Pull off connector -1-.
– Move left headlight range control motor -V48- so that ball head
-2- of left headlight range control motor -V48- can be pulled in
direction of -arrow- out of ball head cup -1-.
– Take left headlight range control motor -V48- out of headlight
housing.
Installing
Carry out installation in the reverse sequence, noting the follow‐
ing:
– Carefully insert ball head of left headlight range control motor
-V48- -1- in ball head cup -arrow-.
Caution
When installing cover cap, ensure cap is seated correctly. The
ingress of water will lead to permanent damage to the head‐
light.
– Check headlight functions.
– Check headlight settings and adjust headlights if necessary
⇒ Maintenance ; Booklet 20.1 ; Descriptions of work .
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
230 Rep. gr.94 - Lights, bulbs, switches - exterior
