2.11 Removing and installing temperature
sensor - G18- and overheating sensor -
G189-
Special tools and workshop equipment required
♦ Torque wrench - V.A.G 1410-
Removing
– Remove cover ⇒ page 19 .
– Unclip wiring harness -1- from retainers -arrows-.
– Unscrew bolt -2-.
– Remove retaining spring -1-.
– Pull out temperature sensor - G18- -4- and overheating sensor
- G189- -3- using long-nose pliers.
Installing
Install in reverse order of removal, observing the following:
– Coat seals from temperature sensor - G18- and overheating
sensor - G189- with coolant for installation.
Note
♦
When assembling, ensure proper position of retaining spring
-1-.
♦
Sensors cannot be renewed individually.
Torque settings
♦ ⇒ “2.2 Assembly overview - auxiliary/supplementary heater,
internal”, page 12
Transporter 2020 ➤
Auxiliary heater - Edition 04.2020
22 Rep. gr.82 - Supplementary heating
