3 Connect the black start cable to the minus (–)
terminal on the auxiliary battery and to a place a
little distance away from the discharged battery,
e.g. the start motor's negative terminal.
WARNING!
The black jumper cable (–) must never come in contact
with the positive connection on the starter motor.
4 Start the engine and let it run at fast idle for
approximately 10 minutes to charge the batteries.
Make sure there is no extra equipment connected
to the electrical system.
WARNING!
Working with or approaching a running engine is a
safety risk. Watch out for rotating components and hot
surfaces.
WARNING!
Do not touch the connections during the start attempt:
Risk of arcing.
Do not bend over any of the batteries either.
5 Turn off the engine. Remove the start cables in the
exact opposite order to their connection.
Emergency Shifting
Emergency shifting, DPH
If a fault occurs which prevents the drive from being
operated (shifted) with the control lever, it is possible to
shift manually, using the description below.
WARNING!
In emergency shifting, the unit is locked in forwards
operation. Please note that the drive can not then be
disengaged with the control lever. Forward motion can
only be cut off by stopping the engine with the ignition
key or stop button..
Manual drive engagement
1 Stop the engine and take the starter key out of the
starter switch.
2 Pull out the split pin (1) and lift the adapter (2) from
the pin (3).
3 Place a screwdriver or similar tool in the adapter (2)
hole and move the control wire horizontally.
In Case of Emergency
47712786 11-2022 © AB VOLVO PENTA 115
