Control Panels
Volvo Penta control panels can be installed in different
combinations. The panels all look the same but are
configured to handle different functionality. The
number of available panels and their function depend
on the boat’s functionality setup.
Start/Stop Panel
The Start/Stop panel is used for starting and stopping
the engine.
To start the engine, the ignition must be switched on at
the main helm station.
Read the starting instructions in the chapter
Starting, page 91 to make sure the correct start
procedure is used.
Station Panel
Activation
Activate the helm station with a single press of the
button.
Further pressure locks the helm station.
To render the helm station inactive, hold the button
down for 3 seconds.
Inactive helm station
Active helm station
Locked helm station
Lowspeed and Powertrim Assistant (PTA)
Depending on the installation the optional functions
lowspeed or Power Trim Assistant are engaged with
the button.
Lowspeed
For further information about the function, refer to Low
Speed.
Powertrim Assistant (PTA)
For further information about the function, refer to Trim
Ranges, page 49.
Neutral button
The gearshift function can be disconnected so that the
control lever only operates the throttle. The neutral
button disengages the drive/reverse gear so that
Instruments and Controls
47712786 11-2022 © AB VOLVO PENTA 25
