Volvo B10M User Manual

22
Handbrake control
The handbrake works on the drive wheels. When the hand
control is in the forward position, with charged air pressure
system and blocking valve depressed (see ”Blocking
valve”) the handbrake is released.
When the control is pulled backwards the handbrake is gradu-
ally engaged and it is fully engaged when the control is in its
rear locked position. Always check that the handbrake is
locked in position.
Articulated buses that have a rigid trailer axle also have a
handbrake on this axle.
Instruments and controls
Handbrake
Never leave the bus without applying the handbrake
and locking it.
To release the handbrake control from the locked position,
lift the ring upwards.
Warning!

Volvo B10M Specifications

General

Chassis	Volvo B10M
Width	2.5 meters
Engine	Volvo THD100 series (TD100, TD101, TD102, TD103)
Production Years	1978-2003
Transmission	ZF, Voith
Configuration	Rear-engined
Suspension	Air suspension
