Instruments and controls
13. Levelling control ...................................................... 30
14. Fire alarm system .................................................... 12
15. Kneeling .................................................................. 30
16. Bogie lift ................................................................... 32
17. Handbrake control .................................................. 22
18. Exhaust brake ......................................................... 27
19. Blocking valve ......................................................... 23
20. Light switch .............................................................. 13
or
20. Feed switch with start and stop buttons ................. 14
21. Starting heater ......................................................... 14
22. Emergency cut-out .................................................. 12
23. Instrument lighting, rheostat ................................... 15
24. EDC engine control system ......................... 39, 82, 85
25. Differential lock ....................................................... 32
26. Retarder switch ....................................................... 28
27. Hand control, retarder ............................................. 28
Warning and indicator lights, see next page
14
12 1234 5 6 7891011
