Volvo V50 Wiring Diagram

TP 39129202 C30/S40 (04-)/V50/C70 (06-) 2009 208
64/10B C70
6-pin gray
No. Roof harness Floor harness
1 4/56H:21 Central Electronic Module
(CEM)
OG-YE
63/218 Branching point
OG-YE
2 4/56H:17 Central Electronic Module
(CEM)
WH-RD
63/217 Branching point
WH-RD
3 3/117:9 Switch unit, ceiling light
BK-YE
63/212 Branching point
BK-YE
4 4/56H:20 Central Electronic Module
(CEM)
BK
64/41:10 Connector
64/43:10 Connector
BK
5 4/56D:4 Central Electronic Module
(CEM)
OG-BU
64/70:1 Connector
OG-BU
6-
-
-
64/25G
10-pin gray
No. Dashboard harness Tunnel harness
1 4/56A:23 Central Electronic Module
(CEM)
GY
9/1:2 Front 12V outlet
GY
2 63/25 Branching point
63/25B Branching point, C70
BK
3/286:5 BLIS or PAS switch
9/1:1 Front 12V outlet C30
63/86B Branching point C70
BK
3 64/545:1 Connector
BU-YE
3/286:1 BLIS switch
BU-YE
3/286:1 PAS switch
OG
4 64/112:7 Connector
64/545:3 Connector
WH
3/286:3 BLIS switch
3/286:3 PAS switch
WH
5-
-
-
-
6 16/1A:8 Integrated Audio Module
(IAM)
-
-
-
7 16/1A:14 Integrated Audio Module
(IAM)
RD-BK
17/40:2 Auxiliary equipment input (AUX)
RD-BK
8 16/1A:7 Integrated Audio Module
(IAM)
BU-GN
17/40:4 Auxiliary equipment input (AUX)
BU-GN
9 16/1A:9 Integrated Audio Module
(IAM)
BU-RD
17/40:1 Auxiliary equipment input (AUX)
BU-RD
10 - -
Connectors
64/10B - 64/25G
