Volvo V50 Wiring Diagram

TP 39129202 C30/S40 (04-)/V50/C70 (06-) 2009 38
Unit Designation
ACM 6/26 Alternator Control Module (ACM)
ADM 4/111 Additive Dosing Module (ADM)
AEM 4/78 Accessory Electronic Module (AEM)
AQS 7/159 Air Quality Sensor (AQS)
AUD 16/105 Audio Module (AUD)
BCM 4/16 Brake Control Module (BCM)
BPM 16/147 Bluetooth Phone Module (BPM)
BSC 7/164 Body Sensor Cluster Stability Sensor (BSC)
CCM 3/112 Climate Control Module (CCM)
CEM 4/56 Central Electronic Module (CEM)
CPM 4/7 Combustion Preheater Module (CPM)
DDM 3/126 Driver Door Module (DDM)
DEM 4/82 Differential Electronic Module (DEM)
DIM 5/1 Driver Information Module (DIM)
DMM 6/48 Damper Motor Module (DMM), recirculation
6/95 Damper Motor Module (DMM), temperature, left side
6/96 Damper Motor Module (DMM), temperature, right side
6/102 Damper Motor Module (DMM), defroster
6/103 Damper Motor Module (DMM), floor/ventilation
ECM 4/46 Engine Control Module (ECM)
EPS 6/71 Electrical Power Steering Module (EPS)
GDL 4/112 Gas Discharge Lamp Module (GDL), master, left
4/113 Gas Discharge Lamp Module (GDL), slave, right
GPS 16/139 Global Positioning System Module (GPS)
GSM 3/156 Gear Selector Module (GSM)
HCM 4/114 Headlamp Control Module (HCM)
IAM 16/1 Integrated Audio Module (IAM)
ICM 3/281 Infotainment Control Module (ICM)
KVM 4/93 Keyless Vehicle Module (KVM)
LCM 4/126 Left Camera Module (LCM)
LDM 3/128 Rear left Door Module (LDM)
MMM 16/108 Multimedia Module (MMM)
OWS 7/93 Occupant Weight Sensor (OWS)
PAM 4/86 Parking Assistance Module (PAM)
PDM 3/127 Passenger Door Module (PDM)
PHM 16/60 Phone Module (PHM)
PSM 4/52 Power Seat Module (PSM)
4/54 Power Seat Module (PSM)
RCM 4/127 Right Camera Module (RCM)
RDM 3/129 Rear Right Door Module (RDM)
RKE 4/119 Signal receiver, keyless vehicle (RKE)
RRX 4/119 Remote Receiver Module (RRX)
RSM 7/149 Rain Sensor Module (RSM)
SCL 4/102 Steering Column Lock Module (SCL)
SCM 16/35 Siren Control Module (SCM)
SCU 3/1 Start Control Module (SCU)
SHM 9/12 Seat Heating Module (SHM), driver’s side
9/13 Seat Heating Module (SHM), passenger side
SRS 4/9 Supplemental Restraint System Module (SRS)
SUB 16/79 Subwoofer Module (SUB)
SWM 3/254 Steering Wheel Module (SWM)
TCM 4/28 Transmission Control Module (TCM)
TRM 4/110 Trailer Module (TRM)
WMM 6/1 Wiper Motor Module (WMM)
Control modules
Overview of designations
