TP 39129202 C30/S40 (04-)/V50/C70 (06-) 2009 36
Grounded directly to chassis
3/4 Switch unit, cruise control (SWS)
3/37 Contact horn
3/47 Parking brake contact
4/9 Supplemental Restraint System Module (SRS)
4/56 Central Electronic Module (CEM)
6/25 Starter motor
6/26 Alternator
7/6 Oil pressure monitor
8/3 Electromagnetic clutch, climate control system
8/33 Igniter, belt tensioner, driver’s side
8/34 Igniter, belt tensioner, passenger side
8/55 Igniter, rear left belt tensioner
8/56 Igniter, rear right belt tensioner
8/66 Igniter, left inflatable curtain
8/67 Igniter, right inflatable curtain
8/128 Driver’s belt force limiter
8/129 Passenger belt force limiter
16/16 Window antenna amplifier
16/67 Antenna amplifier, bumper, C70
16/141 Interference filter, rear window, left
16/142 Interference filter, rear window, right
16/150 AM/FM antenna and amplifier, right rear fender, C70
16/150 Window antenna amplifier, left, C30
18/4 Contact reel
20/22-26 Glow plug
Ground connections
Ground connections in chassis
