Wacker Neuson BTS Series User Manual

Maintenance
T00963GB 53
8.7 Replacing the suction head
The felt filter (13) of the suction head can become clogged. It is
recommended to replace the suction head once every three months in
order to ensure unimpeded fuel flow to the carburetor.
Unscrew the fuel tank cap (12) and pull the loss-prevention stopper
out.
Empty fuel tank.
To remove the suction head for replacement, pull it out through the
tank filler neck using a piece of wire bent at one end to form a hook.
ATTENCION: Do not allow fuel to come into contact with skin!
8.8 Starter rope replacement
Loosen four screws (14). Remove the fan housing (15).
Unscrew 2 screws (16) and carefully remove air duct (17) from fan
housing.
Note and follow sequence (A-B-C-D).
Remove remainders of old rope (18).
